1-door refrigerator 670lt, -2+10°C, digital, AISI 304, R290, Class A
Fast range available in stock. (click to discover more)
Suggested green version.
- Green Benefits
- Features
- Specifications
- Documents
- Accessories
- Energy savings: Reduce your electricity bill by 75%
* with Zanussi NAU Maxi HPe (Class A).
- Energy efficiency: Consumes less than 350 kWh/year for 504L storage, ensuring sustainability and cost savings.
- Storage capacity: Offers 50L
more space than market equivalents with durable AISI 304 stainless steel construction.
*Calculated on a 503lt (net volume) full·door refrigerated cabinet, replacing a class G appliance with a class A.
Main Features
IQ Defrost: fully automatic defrost starts only when ice is actually building-up in the evaporator.
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Airflow: back to front forced air flow and removable air conveyors provide even temperature distribution and fast cooling in any conditions.
Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Provided with stainless steel A304 grids.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Tropicalized unit.
Sustainability
R290 refrigerant to reduce green house and ozone depletion effects.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
The label complies with the delegated regulation (UE) 2015/1094 of the commission of 5th may 2015.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
CFC and HCFC-free insulation.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Improved defrost and evaporator fan management – defrost type changes with temperature set-point: electric below +2°C while air convection defrost above +2°C, thus saving energy.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
User Interface & Data Management
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Construction
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
The rounded internal corners, the easily removable runners, grids and air conveyors allow for ease of cleaning and high hygiene standards.
Easy access to the main components for maintenance.
Stainless steel runners and supports easily disassembled.
Constructed from the highest quality AISI 304 Stainless steel.
Lockable door.
Interior base with rounded corners, pressed from a single sheet.
Capacity:
- Number and type of grids (included): 3 - GN 2/1
Key Information:
- Net Volume: 503 lt
- Capacity: 670 lt / Bottle .75L Bordeaux
- Door hinges:
- External dimensions, Width: 740 mm
- External dimensions, Depth: 860 mm
- External dimensions, Depth with Doors Open: 1480 mm
- External dimensions, Height: 2080 mm
- Number and type of doors: 1 Full
- Type of external material: 304 AISI
- Type of internal material: 304 AISI
- Internal panels material: 304 AISI
- Number of positions & pitch: 44; 30 mm
- Gross capacity: 670 lt
- Type of model (EU Regulation. 2015/1094): vertical chilled
Sustainability
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power: 278 W
- Refrigerant weight: 110 g
- Energy Class (EU Reg. 2015/1094): A
- Yearly and daily energy consumption (EU Reg. 2015/1094): 340kWh/year - 1kWh/24h
- Climate class (EU Reg. 2015/1094): Heavy Duty (5)
- Energy Efficiency Index-EEI (EU Reg. 2015/1094): 23.69
Electric
- Supply voltage: 220-240 V/1 ph/50 Hz
- Electrical power, max: 0.19 kW
Refrigeration Data
- Control type: Digital
- Refrigeration power at evaporation temperature: -10 °C
- Operating mode: Ventilated
