Pastry and Bakery Line
3 Door Refrigerated Counter, -2°/+7°C, 600X400 grid, no top 110907

3-door Refrigerated Counter, 600x400 mm grids, -2+7°C, AISI 304, without top

Where to buy
  • Features
  • Specifications
  • Documents
  • Suitable for use in ambient temperature of up to 40°C (climatic class 5).

  • Adjustable temperature range from -2°C to +7°c.

  • Electronic control panel and digital display.

  • Frontal access for easy maintenance.

  • Internal runners removable without any tools for faster cleaning operations.

  • Adjustable feet from 140mm to 240mm.

  • The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.

  • 3 compartments with 3 doors.

  • Stainless steel AISI 304 internal and external panels including back.

  • Rounded internal corners for ease of cleaning.

  • Self closing doors.

Electric
  • Supply voltage: 230 V/1N ph/50 Hz
  • Electrical power max.: 0.247 kW
Sustainability
  • Energy Class (EU Reg. 2015/1094): A
  • Yearly and daily energy consumption (EU Reg. 2015/1094): 515kWh/year - 1kWh/24h
  • Climate class (EU Reg. 2015/1094): Heavy Duty (5)
  • Energy Efficiency Index-EEI (EU Reg. 2015/1094): 22
  • Refrigerant type: R290
  • GWP Index: 3
Refrigeration Data
  • Control type:
  • Refrigeration power at evaporation temperature: -10 °C
  • Operating temperature min.: -2 °C
  • Operating temperature max.: 7 °C
Key Information:
  • Gross capacity: 545 lt
  • Net Volume: 360 lt
  • N° of doors: 3
  • Door hinges: 1 Left+2 Right
  • External dimensions, Width: 2006 mm
  • External dimensions, Depth: 790 mm
  • External dimensions, Depth with Doors Open: 1280 mm
  • External dimensions, Height: 800 mm
  • Type of external material: Stainless Steel AISI 304 Scotch Brite
  • Type of internal material: 304 AISI
  • Internal side panels material: 304 AISI
Product Information (EU Regulation 2015/1094)
  • Type of model (EU Reg. 2015/1094): counter chilled
CAD Drawings
(105,13 KB)
Data Sheet
Leaflets
(448,89 KB)
Energy Label
(313,17 KB)
(273,31 KB)
BIM/Revit
(1,52 MB)
