2-door Refrigerated Counter, 600x400 mm grids, -2+7°C, AISI 304, without top
- Features
- Specifications
- Documents
-
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.
-
Insulation thickness: 60 mm to ensure effective insulation with minimum energy consumption.
-
Top energy efficiency (class A) and granted uniformity even at extreme working conditions (class 5; 40°C and 40% humidity): unbeatable performance, certified by energy test protocol UNI EN ISO 22041:2020.
-
Suitable for use in ambient temperature of up to 40°C (climatic class 5).
-
Adjustable temperature range from -2°C to +7°c.
-
Electronic control panel and digital display.
-
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
-
Frontal access for easy maintenance.
-
Internal runners removable without any tools for faster cleaning operations.
-
The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.
-
2 compartments with 2 doors.
-
Stainless steel AISI 304 internal and external panels including back.
-
Rounded internal corners for ease of cleaning.
-
Self closing doors.
Electric
- Supply voltage: 230 V/1N ph/50 Hz
- Electrical power max.: 0.247 kW
Product Information (EU Regulation 2015/1094)
- Energy Class: A
- Yearly and daily energy consumption: 448kWh/year - 1kWh/24h
- Climate class: Heavy Duty (5)
- Energy Efficiency Index (EEI): 19
- Type of model: counter chilled
Key Information:
- Gross capacity: 363 lt
- Net Volume: 240 lt
- N° of doors: 2
- Door hinges: 1 Left+1 Right
- External dimensions, Width: 1452 mm
- External dimensions, Depth: 790 mm
- External dimensions, Depth with Doors Open: 1280 mm
- External dimensions, Height: 800 mm
- Type of external material: Stainless Steel AISI 304 Scotch Brite
- Type of internal material: 304 AISI
- Internal side panels material: 304 AISI
Refrigeration Data
- Control type:
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power at evaporation temperature: -10 °C
- Operating temperature min.: -2 °C
- Operating temperature max.: 7 °C
