NPT Active HPe
1 Door Digital Freezer, 670lt (-22/-15) - R290 - Class B
111320

1-door freezer 670lt, -22-15°C, digital, AISI 304, R290, Class B

Suggested green version.

Where to buy
  • Green Benefits
  • Features
  • Specifications
  • Documents
  • Accessories
  • Energy savings: Reduce your electricity bill up to 68%
    * with Zanussi NPT Active HPe (Class B).
  • Storage capacity: Offers 50L more space than market equivalents with durable AISI 304 stainless steel construction.
  • Smart performance: Frost Watch Control optimizes defrosting by minimizing temperature fluctuations, reducing bacteria, food waste, and energy consumption.
  • Easy to use: Bluetooth

app management and remote monitoring for seamless operation.

*Calculated on a 503lt (net volume) full·door freezer cabinet, replacing a class G appliance with a class B.
  • Freezer model has operating temperatures that can be adjusted from -22 to -15 °C.

  • Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).

  • Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.

  • Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).

  • 60 mm-thick insulation covering the evaporator can be easily removed with a single operation.

  • Optiflow: back to front forced air flow and removable air conveyors provide even temperature distribution and fast cooling in any conditions.

  • Digital control panel allowing the easy and precise setting and control of the internal temperature.

  • Easy serviceability thanks to the intuitive control panel with access via app.

  • Zanussi Professional Fridge Control APP make the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/turbocooling​ and set date/hour

  • Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to 30 days of event are kept in memory.

  • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

  • Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.

  • Rilsan coated grids for improved protection.

  • Tropicalized unit.

  • Constructed from the highest quality AISI 304 Stainless steel.

  • Interior base with rounded corners, pressed from a single sheet.

  • The rounded internal corners, the easily removable runners, grids and air conveyors allow for ease of cleaning and high hygiene standards.

  • Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.

  • Easy access to the main components for maintenance.

  • Lockable door.

Capacity:
  • Number and type of grids (included): 4 - GN 2/1
Key Information:
  • Net Volume: 503 lt
  • Door hinges:
  • External dimensions, Width: 740 mm
  • External dimensions, Depth: 885 mm
  • External dimensions, Depth with Doors Open: 1507 mm
  • External dimensions, Height: 2080 mm
  • Number and type of doors: 1 Full
  • Type of external material: 304 AISI
  • Type of internal material: 304 AISI
  • Internal panels material: 304 AISI
  • Number of positions & pitch: 44; 30 mm
  • Gross capacity: 670 lt
  • Type of model (EU Regulation. 2015/1094): vertical frozen
Sustainability
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power: 569 W
  • Refrigerant weight: 90 g
  • Energy Class (EU Reg. 2015/1094): B
  • Yearly and daily energy consumption (EU Reg. 2015/1094): 1325kWh/year - 4kWh/24h
  • Climate class (EU Reg. 2015/1094): Heavy Duty (5)
  • Energy Efficiency Index-EEI (EU Reg. 2015/1094): 33.54
Electric
  • Supply voltage: 220-240 V/1 ph/50 Hz
  • Electrical power, max: 0.3 kW
Refrigeration Data
  • Control type: Digital
  • Refrigeration power at evaporation temperature: -30 °C
  • Operating temperature min.: -15 °C
  • Operating temperature max.: -22 °C
  • Operating mode: Ventilated
Data Sheet
Leaflets
Energy Label
(317,69 KB)
(278,04 KB)
Included Accessories
Quantity
Code
Description
Quantity: 4
Code: 881020
2/1GN grey rilsan grid with 2 runners
