NPT Active
1 Glass Door Digital Refrigerator, 670lt (+2/+10) R290
- Features
- Specifications
- Documents
- Accessories
-
Led lights on the door guarantee an even light in the cavity.
-
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
-
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
-
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
-
Digital temperature display and setting +2/+10 °C.
-
Internal structure with 44 charging positions available to host grids, ensuring higher net capacity and a greater storage space.
-
Possibility to select 3 different levels of humidity according with the type of food stored inside.
-
Zanussi Professional Fridge Control APP make the life easier for our customers: - Monitor safety of preservation process thanks to HACCP data & alarms for precise control- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address- Quick operations: set the cabinet temperature/humidity/turbocooling and set date/hour
-
Large digital white-digit display with cabinet temperature display and setting, and possibility to select the desired levels of humidity. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
-
Cabinet fitted with up to 75 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
-
Tropicalized unit.
-
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
-
Performance guaranteed at ambient temperatures of +32°C.
-
Right hinged glass door with heated frame.
-
The operating temperature can be adjusted from +2 to +10°C to suit both meat and dairy storage requirements.
-
Optiflow: back to front forced air flow and removable air conveyors provide even temperature distribution and fast cooling in any conditions.
-
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
-
Large digital white-digit display with cabinet temperature display and setting, manual activation of defrost cycle, turbo frost cycle (to rapidly cool warm loads) and internal light switch.
-
Rilsan coated grids for improved protection.
-
Interior base with rounded corners, pressed from a single sheet.
-
Lockable door.
-
Constructed from the highest quality AISI 304 Stainless steel.
-
Easy access to the main components for maintenance.
-
Stainless steel runners and supports easily disassembled.
-
The rounded internal corners, the easily removable runners, grids and air conveyors allow for ease of cleaning and high hygiene standards.
-
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Capacity:
- Number and type of grids (included): 4 - GN 2/1
Key Information:
- Net Volume: 503 lt
- Capacity: 670 lt / Bottle .75L Bordeaux
- External dimensions, Width: 710 mm
- External dimensions, Depth: 835 mm
- External dimensions, Depth with Doors Open: 1480 mm
- External dimensions, Height: 2050 mm
- Number and type of doors: 1 Glass
- Type of external material: 304 AISI
- Type of internal material: 304 AISI
- Internal panels material: 304 AISI
- Number of positions & pitch: 44; 30 mm
- Gross capacity: 670 lt
- Type of model (EU Regulation. 2015/1094): vertical chilled
Sustainability
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power: 322 W
- Energy Class (EU Reg. 2015/1094): D
- Yearly and daily energy consumption (EU Reg. 2015/1094): 945kWh/year - 3kWh/24h
- Climate class (EU Reg. 2015/1094): Normal duty (cl.4)
- Energy Efficiency Index-EEI (EU Reg. 2015/1094): 65,83
Electric
- Supply voltage: 220-240 V/1 ph/50 Hz
- Electrical power max: 0.3 kW
Refrigeration Data
- Control type: Digital
- Refrigeration power at evaporation temperature: -10 °C
- Operating temperature min.: 2 °C
- Operating temperature max.: 10 °C
- Compressor power: 1/4 hp
- Operating mode: Ventilated
CAD Drawings
Data Sheet
Energy Label
BIM/Revit
Included Accessories
