NAU Maxi HPe
1 Door Digital Refrigerator, 670lt (-2+10) - R290 - Class A
111134

1-door refrigerator 670lt, -2+10°C, digital, stainless steel, R290, Class A

Suggested green version.

Where to buy
  • Green Benefits
  • Features
  • Specifications
  • Documents
  • Accessories
  • Energy savings: Reduce your electricity bill by 75%
    * with Zanussi NAU Maxi HPe (Class A).
  • Energy efficiency: Consumes less than 350 kWh/year for 504L storage, ensuring sustainability and cost savings.
  • Storage capacity: Offers 50L

more space than market equivalents with durable AISI 304 stainless steel construction.

*Calculated on a 503lt (net volume) full·door refrigerated cabinet, replacing a class G appliance with a class A.
  • Main Features

  • Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.

  • Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.

  • 60 mm-thick insulation covering the evaporator can be easily removed with a single operation.

  • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

  • Rilsan coated grids for improved protection.

  • Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.

  • Tropicalized unit.

  • Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.

  • Automatic defrost.

  • Easy serviceability thanks to the intuitive control panel with access via app.

  • Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.

  • Equipped with single phase electrical cable and Schuko plug for easy and fast installation.

  • Right hinged full door.

  • Sustainability

  • Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).

  • Automatic evaporation of the defrosting water by hot gas on the top for energy saving.

  • Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.

  • Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

  • CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

  • Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.

  • Construction

  • Easy access to the main components for maintenance.

  • Stainless steel runners and supports easily disassembled.

  • Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.

  • Doors are self-closing and can be fully opened up to 180°.

  • Lockable door.

  • The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.

  • AISI 430 stainless steel internal structure and external panels.

  • Mounted on adjustable Stainless steel feet, with castors as an option.

Capacity:
  • Number and type of grids (included): 3 - GN 2/1
Key Information:
  • Net Volume: 503 lt
  • Door hinges:
  • External dimensions, Width: 740 mm
  • External dimensions, Depth: 860 mm
  • External dimensions, Depth with Doors Open: 1480 mm
  • External dimensions, Height: 2050 mm
  • Number and type of doors: 1 Full
  • Type of external material: Stainless Steel
  • Type of internal material: Stainless Steel
  • Internal panels material: Stainless Steel
  • Number of positions & pitch: 44; 30 mm
  • Gross capacity: 670 lt
  • Type of model (EU Regulation. 2015/1094): vertical chilled
Sustainability
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power: 229 W
  • Refrigerant weight: 110 g
  • Energy Class (EU Reg. 2015/1094): A
  • Yearly and daily energy consumption (EU Reg. 2015/1094): 340kWh/year - 1kWh/24h
  • Climate class (EU Reg. 2015/1094): Heavy Duty (5)
  • Energy Efficiency Index-EEI (EU Reg. 2015/1094): 23.69
Electric
  • Supply voltage: 220-240 V/1 ph/50 Hz
  • Electrical power, max: 0.19 kW
Refrigeration Data
  • Control type: Digital
  • Refrigeration power at evaporation temperature: -10 °C
  • Operating temperature min.: -2 °C
  • Operating temperature max.: 10 °C
  • Compressor power: 1/4 hp
  • Operating mode: Ventilated
Data Sheet
Energy Label
(315,23 KB)
(275,44 KB)
BIM/Revit
(904 KB)
Included Accessories
Quantity
Code
Description
Quantity: 3
Code: 881020
2/1GN grey rilsan grid with 2 runners
