Main Features
Digital control with cabinet temperature display and setting, manual activation of defrost cycle and internal light switch. Fully compliant HACCP digital controls include visible alarms.
Adjustable temperature range from -15°C to -20°C to suit all storage requirements.
Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Cabinet fitted with up to 75 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Rilsan coated grids for improved protection.
Right hinged glass door.
Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.
Led lights on the door guarantee an even light in the cavity.
Performance guaranteed at ambient temperatures of +32°C.
Mounted on adjustable stainless steel legs.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
Automatic defrost.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Tropicalized unit.
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
Right hinged full door.
This appliance is intended for use in ambient temperatures up to 40°C.
Digital control with cabinet temperature display and setting and manual activation of defrost cycle. Fully compliant HACCP digital controls include visible alarms.
Sustainability
CFC and HCFC-free insulation.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Construction
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Doors are self-closing and can be fully opened up to 180°.
The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.
Constructed from the highest quality AISI 304 Stainless steel.
Easy access to the main components for maintenance.
Remote refrigeration unit.
Stainless steel runners and supports easily disassembled.
Refrigerant type: R290.
Lockable door.
Interior base with rounded corners, pressed from a single sheet.
Mounted on adjustable Stainless steel feet, with castors as an option.
Capacity:
- Number and type of grids (included): 3 - GN 2/1
Key Information:
- External dimensions, Width: 710 mm
- External dimensions, Depth: 835 mm
- External dimensions, Depth with Doors Open: 1480 mm
- External dimensions, Height: 2050 mm
- Number and type of doors: 1 Glass
- Type of external material: 304 AISI
- Type of internal material: 304 AISI
- Internal panels material: 304 AISI
- Number of positions & pitch: 44; 30 mm
- Gross capacity: 670 lt
Sustainability
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power: 569 W
Electric
- Supply voltage: 220-240 V/1 ph/50 Hz
- Electrical power, max: 0.65 kW
Refrigeration Data
- Control type: Digital
- Refrigeration power at evaporation temperature: -30 °C
- Operating temperature min.: -20 °C
- Operating temperature max.: -15 °C
- Operating mode: Ventilated
CAD Drawings
Data Sheet
Energy Label
BIM/Revit
Included Accessories
