NPT AU Line
Refrigerated Counter 2 Doors (R290) 111161

2-door refrigerated counter, -2+10°C (R290), AISI 304

Where to buy
  • Features
  • Specifications
  • Documents
  • Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.

  • Self closing stainless steel doors (< 90°).

  • Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

  • Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

  • Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

  • Tropicalized unit (43°C ambient temperature).

  • 0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.

  • Hot gas automatic evaporation of defrost water.

  • Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.

  • Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).

  • Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.

  • Frontal and easy access to all components in the cooling unit.

  • Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.

  • Certified safety CE requirements.

  • Small footprint to fit even in limited environments.

  • Kit 1/3 drawers available as accessory.

  • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

  • Digital control panel.

  • Anti-tilt runners accept GN 1/1 containers.

  • Forced air circulation for rapid cooling and an even temperature distribution.

  • Refrigerated compartment designed to accept GN 1/1 containers.

  • Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.

  • Digital control panel allowing the easy and precise setting and control of the internal temperature.

  • Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.

  • Complies with main international certification bodies and is CE marked.

  • Kit 1/2 drawers available as accessory.

  • The door self-closes when opened less than at a 90° angle and is equipped with a door seal to guarantee perfect closure.

  • Completely automatic defrosting and automatic evaporation of defrost water by hot gas.

  • Forced air cooling system guaranteeing great uniformity of the temperature in the counter and excellent conservation of the food quality.

  • High standards of hygiene and ease of cleaning are guaranteed by the rounded internal corners of the cabinet and easily removable runners and grids.

  • Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

  • Developed and produced in ISO 9001 and ISO 14001 certified factory.

  • Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.

  • Internal and external doors, front, back and side panels in AISI 304 Stainless steel.

  • Extractable cooling unit to facilitate maintenance.

  • IP21 protection index.

  • Access to all components from the front.

  • Fault code display.

  • Interior base with rounded corners, pressed from a single sheet.

  • Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.

  • Rounded internal corners for ease of cleaning.

  • Built-in refrigeration unit.

  • Pre-arranged for drain-pipe.

  • External back panel in galvanized steel.

  • Built-in compressor to suit operating conditions.

  • Legs in 304 AISI stainless steel (150 mm high, adjustable in height), with plastic interior.

  • Insulation guaranteed by high density expanded cyclopenthane 50 mm in thickness.

  • Internal and external doors, front and side panels and 50mm thick removable worktop in 304 AISI stainless steel.

Electric
  • Supply voltage: 220-240 V/1 ph/50 Hz
  • Electrical power max.: 0.22 kW
Product Information (EU Regulation 2015/1094)
  • Energy Class: B
  • Yearly and daily energy consumption: 560kWh/year - 2kWh/24h
  • Climate class: Heavy Duty (5)
  • Energy Efficiency Index (EEI): 25,36
Key Information:
  • Gross capacity: 290 lt
  • Net Volume: 163.6 lt
  • External dimensions, Width: 1245 mm
  • External dimensions, Depth with Doors Open: 1310 mm
  • External dimensions, Height: 850 mm
  • Net weight: 94 kg
  • Noise level: 48 dBA
  • Worktop type: Stainless Steel
  • Built-in Compressor and Refrigeration Unit
Refrigeration Data
  • Control type: Digital
  • Compressor power: 1/4 hp
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power: 320 W
  • Refrigerant weight: 50 g
  • Min/Max internal humidity: 40/85
  • Operating temperature min.: -2 °C
  • Operating temperature max.: 10 °C
  • Operating mode: Ventilated
CAD Drawings
(351,59 KB)
Data Sheet
Energy Label
(314,82 KB)
(275,01 KB)
BIM/Revit
(1,02 MB)
