Digital control panel.

Digital control panel with temperature display.

Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.

Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.

Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.

Adjustable temperature range from -15 °C to -20 °C to suit meat, fish and dairy storage requirements.

Small footprint to fit even in limited environments.

Refrigerated compartment designed to accept GN 1/1 containers.

Anti-tilt runners accept GN 1/1 containers.

Adjustable temperature range from -15°C to -22°C.

Equipped with Airflow system: forced air circulation system for rapid cooling and even temperature distribution within the cell.

0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.

Frontal and easy access to all components in the cooling unit.

Self closing stainless steel doors (< 90°).

Tropicalized unit.

Certified safety CE requirements.

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Freezer compartment designed to accept GN1/1 containers.

Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.

Forced air circulation for rapid cooling and an even temperature distribution.

CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).

Hot gas automatic evaporation of defrost water.

Easy serviceability thanks to the intuitive control panel with access via app.

Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

Interior base with rounded corners, pressed from a single sheet.

Pre-arranged for drain-pipe.

Fault code display.

Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

Access to all components from the front.

Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.

Built-in compressor to suit operating conditions.

Internal and external doors, front, back and side panels in AISI 304 Stainless steel.

Built-in refrigeration unit.

Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.

Extractable cooling unit to facilitate maintenance.

2 compartments with 2 doors.

Anti-drip profile on stainless steel worktop edge.

IP21 protection index.

If needed, working top can be removed for easier handling during installation (in case of narrow doors).

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.

Worktop in AISI 304 Stainless steel with a 50 mm profile.

External back panel in galvanized steel.

Rounded internal corners for ease of cleaning.

Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
