Pastry and Bakery Line
3 Door Refrigerated Counter, -2°/+7°C, 600X400 grid, with upstand 110909

3-door Refrigerated Counter, 600x400 mm grids, -2+7°C, AISI 304, with upstand

Where to buy
  • Features
  • Specifications
  • Documents
  • Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.

  • Insulation thickness: 60 mm to ensure effective insulation with minimum energy consumption.

  • Top energy efficiency (class A) and granted uniformity even at extreme working conditions (class 5; 40°C and 40% humidity): unbeatable performance, certified by energy test protocol UNI EN ISO 22041:2020.

  • Suitable for use in ambient temperature of up to 40°C (climatic class 5).

  • Adjustable temperature range from -2°C to +7°c.

  • Electronic control panel and digital display.

  • Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

  • Frontal access for easy maintenance.

  • Internal runners removable without any tools for faster cleaning operations.

  • The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.

  • 3 compartments with 3 doors.

  • Stainless steel AISI 304 internal and external panels including back.

  • Rounded internal corners for ease of cleaning.

  • Self closing doors.

Electric
  • Supply voltage: 230 V/1N ph/50 Hz
  • Electrical power max.: 0.247 kW
Product Information (EU Regulation 2015/1094)
  • Energy Class: A
  • Yearly and daily energy consumption: 515kWh/year - 1kWh/24h
  • Climate class: Heavy Duty (5)
  • Energy Efficiency Index (EEI): 22
  • Type of model: counter chilled
Key Information:
  • Gross capacity: 545 lt
  • Net Volume: 360 lt
  • N° of doors: 3
  • Door hinges: 1 Left+2 Right
  • External dimensions, Width: 2006 mm
  • External dimensions, Depth: 800 mm
  • External dimensions, Depth with Doors Open: 1280 mm
  • External dimensions, Height: 950 mm
  • Type of external material: Stainless Steel AISI 304 Scotch Brite
  • Type of internal material: 304 AISI
  • Internal side panels material: 304 AISI
Refrigeration Data
  • Control type:
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power at evaporation temperature: -10 °C
  • Operating temperature min.: -2 °C
  • Operating temperature max.: 7 °C
CAD Drawings
(108,59 KB)
Data Sheet
Energy Label
(314,54 KB)
(274,65 KB)
BIM/Revit
(1,25 MB)
