Pastry and Bakery Line
2 Door Freezer Counter, -24°/-10°C, 600X400 grid, with upstand 110913

2-door Freezer Counter, 600x400 mm grids, -10-24°C, AISI 304, with upstand

Where to buy
  • Features
  • Specifications
  • Documents
  • Suitable for use in ambient temperature of up to 40°C (climatic class 5).

  • Adjustable temperature range from –10°C to -24°C.

  • Completely automatic defrosting and automatic evaporation of defrost water by hot gas.

  • Electronic control panel and digital display.

  • Frontal access for easy maintenance.

  • Internal runners removable without any tools for faster cleaning operations.

  • Adjustable feet from 140mm to 240mm.

  • The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.

  • 2 compartments with 2 doors.

  • Stainless steel AISI 304 internal and external panels including back.

  • Rounded internal corners for ease of cleaning.

  • Self closing doors.

Electric
  • Supply voltage: 230 V/1N ph/50 Hz
  • Electrical power max.: 0.413 kW
Sustainability
  • Energy Class (EU Reg. 2015/1094): D
  • Yearly and daily energy consumption (EU Reg. 2015/1094): 2473kWh/year - 7kWh/24h
  • Climate class (EU Reg. 2015/1094): Heavy Duty (5)
  • Energy Efficiency Index-EEI (EU Reg. 2015/1094): 65
  • Refrigerant type: R290
  • GWP Index: 3
Refrigeration Data
  • Control type:
  • Refrigeration power at evaporation temperature: -30 °C
  • Operating temperature min.: -24 °C
  • Operating temperature max.: -10 °C
Key Information:
  • Gross capacity: 363 lt
  • Net Volume: 240 lt
  • N° of doors: 2
  • Door hinges: 1 Left+1 Right
  • External dimensions, Width: 1452 mm
  • External dimensions, Depth: 800 mm
  • External dimensions, Depth with Doors Open: 1280 mm
  • External dimensions, Height: 950 mm
  • Type of external material: Stainless Steel AISI 304 Scotch Brite
  • Type of internal material: 304 AISI
  • Internal side panels material: 304 AISI
Product Information (EU Regulation 2015/1094)
  • Type of model (EU Reg. 2015/1094): counter frozen
CAD Drawings
(107,66 KB)
Data Sheet
Leaflets
(448,89 KB)
Energy Label
(315,4 KB)
(275,58 KB)
BIM/Revit
(1,45 MB)
