2 Door Freezer Counter, -24°/-10°C, 600X400 grid, with upstand 110913
2-door Freezer Counter, 600x400 mm grids, -10-24°C, AISI 304, with upstand
- Features
- Specifications
- Documents
-
Suitable for use in ambient temperature of up to 40°C (climatic class 5).
-
Adjustable temperature range from –10°C to -24°C.
-
Completely automatic defrosting and automatic evaporation of defrost water by hot gas.
-
Electronic control panel and digital display.
-
Frontal access for easy maintenance.
-
Internal runners removable without any tools for faster cleaning operations.
-
Adjustable feet from 140mm to 240mm.
-
The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.
-
2 compartments with 2 doors.
-
Stainless steel AISI 304 internal and external panels including back.
-
Rounded internal corners for ease of cleaning.
-
Self closing doors.
Electric
- Supply voltage: 230 V/1N ph/50 Hz
- Electrical power max.: 0.413 kW
Sustainability
- Energy Class (EU Reg. 2015/1094): D
- Yearly and daily energy consumption (EU Reg. 2015/1094): 2473kWh/year - 7kWh/24h
- Climate class (EU Reg. 2015/1094): Heavy Duty (5)
- Energy Efficiency Index-EEI (EU Reg. 2015/1094): 65
- Refrigerant type: R290
- GWP Index: 3
Refrigeration Data
- Control type:
- Refrigeration power at evaporation temperature: -30 °C
- Operating temperature min.: -24 °C
- Operating temperature max.: -10 °C
Key Information:
- Gross capacity: 363 lt
- Net Volume: 240 lt
- N° of doors: 2
- Door hinges: 1 Left+1 Right
- External dimensions, Width: 1452 mm
- External dimensions, Depth: 800 mm
- External dimensions, Depth with Doors Open: 1280 mm
- External dimensions, Height: 950 mm
- Type of external material: Stainless Steel AISI 304 Scotch Brite
- Type of internal material: 304 AISI
- Internal side panels material: 304 AISI
Product Information (EU Regulation 2015/1094)
- Type of model (EU Reg. 2015/1094): counter frozen
