Pastry and Bakery Line
2 Door Freezer Counter, -24°/-10°C, 600X400 grid, no top
- Features
- Specifications
- Documents
- Accessories
Main Features
Suitable for use in ambient temperature of up to 40°C (climatic class 5).
Adjustable temperature range from –10°C to -24°C.
Completely automatic defrosting and automatic evaporation of defrost water by hot gas.
Electronic control panel and digital display.
Frontal access for easy maintenance.
Internal runners removable without any tools for faster cleaning operations.
Sustainability
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.
Insulation thickness: 60 mm to ensure effective insulation with minimum energy consumption.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Construction
Adjustable feet from 140mm to 240mm.
The position of the evaporator and the design of the internal ventilation facilitate the uniformity of the temperature.
2 compartments with 2 doors.
Stainless steel AISI 304 internal and external panels including back.
Rounded internal corners for ease of cleaning.
Self closing doors.
Electric
- Supply voltage: 230 V/1N ph/50 Hz
- Electrical power, max: 0.41 kW
Refrigeration Data
- Control type:
- Refrigeration power at evaporation temperature: -30 °C
- Operating temperature min.: -24 °C
- Operating temperature max.: -10 °C
Key Information:
- Net Volume: 240 lt
- N° of doors: 2
- Door hinges:
- External dimensions, Width: 1452 mm
- External dimensions, Depth: 790 mm
- External dimensions, Depth with Doors Open: 1280 mm
- External dimensions, Height: 800 mm
- Type of external material: Stainless Steel AISI 304 Scotch Brite
- Type of internal material: 304 AISI
- Internal side panels material: 304 AISI
- Gross capacity: 363 lt
- Type of model (EU Regulation. 2015/1094): counter frozen
Sustainability
- Refrigerant type: R290
- GWP Index: 3
- Energy Class (EU Reg. 2015/1094): D
- Yearly and daily energy consumption (EU Reg. 2015/1094): 2473kWh/year - 7kWh/24h
- Climate class (EU Reg. 2015/1094): Heavy Duty (5)
- Energy Efficiency Index-EEI (EU Reg. 2015/1094): 65
CAD Drawings
Data Sheet
Leaflets
Energy Label
BIM/Revit
Included Accessories
